.99The cycling equivalent of an SUV; stylish and practical. 29" wheels make for effortless cycling. The fast and grippy 2.2" Kenda Booster tyres fit neatly inside the mudguards for year round practicality.
The bent top tube provides a really low standover height for easy mounting and dismounting and a more confident ride.
Some of the technical features and thinking from the award winning Merida eOne-Sixty make an appearance, including the satellite charging socket, a double compound battery compartment cover and a neat bottle boss system incorporating tidy cable routing.
The list of well thought through details include tyres with reflective strips, a rack with an integrated rear light, a Leyzyne front light, an integrated lock and a kick stand.
We accept Cycle Scheme
Save up to £1,260
Pay with Cycle Scheme
Great bike. Great Service & excellent communication. Very happy.
Specification| Availability | In stock |
|---|---|
| BIKE year | 2023 |
| Category | Hybrid |
| Colour | Blue , black |
| Condition | Brand new |
| battery | 630 Wh |
| bottom bracket | Part of Shimano Steps motor |
| brake levers | Shimano M4100 |
| cassette | KMC e11S EPT |
| chain | KMC e11S EPT |
| chainset | Shimano CRE70-B; 34 tooth chainring with Shimano FCEM600; 165mm length crank |
| display | Shimano SC-E5003A |
| fork | Suntour XCR34 LOR DS; Air, Boost; 100mm; Tapered; 51mm fork offset. Max. tyre size: 29inch x 2.4inch |
| frame | Lite III - Hydroformed 6066 aluminium, intergrated battery, internal cable routing, Smart entry ports. Tapered head tube, 148 x 12mm axle standard. Mounts for mudguards and kickstand. Max. tyre size 29inchx2.25inch with mudguards, 29inchx2.35inch witho |
| front brake | Shimano M4100; 4 piston hydraulic disc brake caliper with Shimano RT30; 180mm rotor |
| grips | Merida Expert TK |
| handlebar | Merida Expert CC; aluminium; 720mm wide; 10mm rise |
| headset | Merida-8155 |
| hub front | Shimano MT400-B; 110x15mm; 32 spokes; Center lock |
| hub rear | Shimano MT400-B; 148x12mm; 36 spokes; Center lock; including removable lever with 4/6mm Allen key |
| motor | Shimano E8036; 630Wh internal battery, Shimano Steps EP8; 85Nm |
| pedal | VP Components, VPE-537 |
| rear brake | Shimano M4100; 2 piston hydraulic disc brake caliper with Shimano RTEM300; 180 mm rotor |
| rear derailleur | Shimano Deore RDM5100 11 |
| rims | Merida Comp CC; 20mm inner rim width; Aluminium |
| saddle | Merida Expert TK; V-mount |
| seatpost | Merida Expert CC; aluminium; 34.9mm diameter; in-line |
| shift levers | Shimano Deore M5100 |
| spokes | Black stainless |
| stem | Merida Expert CT; aluminium; 31.8mm diameter; adjustable - Stem length: 90mm all sizes |
| tyres | Front tyre: Kenda Booster; 29inch x 2.2inch; wire bead Rear tyre: Kenda Booster; 29inch x 2.2inch; wire bead |
| MPN | A62211A01339 |
| PNUM | 19362 |
| PRICE | £2999.99 |
| Available now |
Size guide| RIDER HEIGHT | FRAME SIZE SUGGESTED | |||
|---|---|---|---|---|
| (ft - in) | (cm) | (in) | Size | (cm) |
| 4' 10" - 5' 1" | 147 - 155 | 13 - 14 | XS | 47 - 49 |
| 5' 1" - 5' 5" | 155 - 165 | 15 - 16 | S | 50 - 52 |
| 5' 5" - 5' 9" | 165 - 175 | 17 - 18 | M | 53 - 54 |
| 5' 9" - 6' 0" | 175 - 183 | 19 - 20 | L | 55 - 57 |
| 6' 0" - 6' 3" | 183 - 191 | 21 - 22 | XL | 58 - 61 |
| 6' 3" - 6' 6" | 191 - 198 | 23 - 25 | XXL | 61 - 63 |
